Kapasitor Keramik 470pf Tahan Air Stabil, Kapasitor Keamanan AC Multifungsi

Gambar besar : Kapasitor Keramik 470pf Tahan Air Stabil, Kapasitor Keamanan AC Multifungsi

Detail produk:

Tempat asal:	Cina
Sertifikasi:	UL VDE CQC KTL
Nomor model:	Y1 47K/400V K L3.5mm

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1000 PCS
Kemasan rincian:	1000 PCS
Waktu pengiriman:	2-5 hari kerja
Syarat-syarat pembayaran:	T/T
Menyediakan kemampuan:	5000000 pcs per bulan

Kontak

Kapasitor Keramik 470pf Tahan Air Stabil, Kapasitor Keamanan AC Multifungsi

Deskripsi

Bahan:	Keramik Pengaman tegangan AC	jenis paket:	Melalui Lubang, massal
Karakteristik Suhu:	Y5U	kapasitansi:	470PF
Nilai Tegangan::	400VAC	Suhu Operasional:	-25 ~125℃
Toleransi kapasitansi:	± 10%	Jarak Timbal (mm):	10
Cahaya Tinggi:	Kapasitor Keramik 470pf Stabil , Kapasitor Keramik 470pf Tahan Air , Kapasitor Keselamatan AC Multifungsi

Kapasitor Wafer Keramik Keamanan Tegangan Ac Y1 -471K 400V Y5U

Parameter produk

Standar Referensi Spesifikasi	IEC 60384-14 ;EN 60384-14 ;IEC UL60384 ;K 60384
Monogram yang Disetujui	VDE / ENEC / IEC / UL / CSA / KC / CQC
Subkelas ;Nilai Tegangan (UR)	X1 / Y1/Y2 ;400VAC / 250VAC
Rentang kapasitansi	10pF hingga 10000pF
Bukti Tegangan	4000VAC selama 1 menit/2000VAC selama 1 menit/1800VAC selama 1 menit
Toleransi kapasitansi	Y5P±10%(K) ;Y5U,Y5V±20%(M) diukur pada 25℃,1Vrms,1KHz
Faktor Disipasi (tgδ)	Y5P,Y5U tgδ≤2,5% ;Y5V tgδ≤5% diukur pada 25℃,1Vrms,1KHz
Resistansi Isolasi (IR)	IR≥10000MΩ,1 menit,100VDC
Suhu Operasional	-40℃ hingga +85℃ ;-40℃ hingga +125℃
Karakteristik Suhu	Y5P, Y5U, Y5V
Epoxy Tahan Api	UL94-V0

Spesifikasi produk seri penuh kapasitor Y1 standar keselamatan

Spesifikasi tipe	lebar	ketebalan	Pin pitch	Memimpin	Tegangan	kapasitas	bahan	toleransi
Y1-472M-Y5V	11.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	4700pF	Y5V	±20%
Y1-332M-Y5V	10mm	T4.5mm	F10mm	L3-22mm	400V[**]C	3300pF	Y5V	±20%
Y1-222M-Y5V	8.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	2200pF	Y5V	±20%
Y1-152M-Y5V	7.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	1500pF	Y5V	±20%
Y1-102M-Y5V	6.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	1000pF	Y5V	±20%
Y1-472M-Y5U	13.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	4700pF	Y5U	±20%
Y1-332M-Y5U	11.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	3300pF	Y5U	±20%
Y1-222M-Y5U	10mm	T4.5mm	F10mm	L3-22mm	400V[**]C	2200pF	Y5U	±20%
Y1-152M-Y5U	9mm	T4.5mm	F10mm	L3-22mm	400V[**]C	1500pF	Y5U	±20%
Y1-102M-Y5U	7.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	1000pF	Y5U	±20%
Y1-821K-Y5U	7.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	820pF	Y5U	±10%
Y1-681K-Y5U	7.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	680pF	Y5U	±10%
Y1-561K-Y5U	7.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	560pF	Y5U	±10%
Y1-471K-Y5U	6.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	470pF	Y5U	±10%
Y1-102K-Y5P	11.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	1000pF	Y5P	±10%
Y1-821K-Y5P	11mm	T4.5mm	F10mm	L3-22mm	400V[**]C	820pF	Y5P	±10%
Y1-681K-Y5P	9.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	680pF	Y5P	±10%
Y1-561K-Y5P	8.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	560pF	Y5P	±10%
Y1-471K-Y5P	8.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	470pF	Y5P	±10%
Y1-331K-Y5P	7.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	330pF	Y5P	±10%
Y1-221K-Y5P	6.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	220pF	Y5P	±10%
Y1-151K-Y5P	6.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	150pF	Y5P	±10%
Y1-101K-Y5P	6.5mm	T4.5mm	F10mm	L3-22mm	400V[**]C	100pF	Y5P	±10%
Y1-820K-Y5P	7mm	T4mm	F10mm	L3-22mm	400V[**]C	82pF	Y5P	±10%
Y1-680K-Y5P	7mm	T4mm	F10mm	L3-22mm	400V[**]C	62pF	Y5P	±10%
Y1-560K-Y5P	7mm	T4mm	F10mm	L3-22mm	400V[**]C	56pF	Y5P	±10%
Y1-470K-Y5P	7mm	T4mm	F10mm	L3-22mm	400V[**]C	47pF	Y5P	±10%
Y1-330K-Y5P	7mm	T4mm	F10mm	L3-22mm	400V[**]C	33pF	Y5P	±10%
Y1-220K-Y5P	7mm	T4mm	F10mm	L3-22mm	400V[**]C	22pF	Y5P	±10%
Y1-150K-Y5P	6.5mm	T4mm	F10mm	L3-22mm	400V[**]C	15pF	Y5P	±10%
Y1-100K-Y5P	6.5mm	T4mm	F10mm	L3-22mm	400V[**]C	10pF	Y5P	±10%

Label:

Kapasitor Keselamatan Y1 Tahan Api,

Kapasitor Keselamatan CQC Y1,

Tahan Air x kapasitor y kapasitor
